Transcell BSS-5K S-Beam Load Cell 5000 lb.

$299.95 Reg. Price $350.00   You Save $50.05
5000 lb. max capacity tool steel S-Type load cell that is ideally suited for scale conversions and general purpose weighing. Compact and rugged design. Complete with 20'/6.1 m of load cell cable. non ntep. Similar to RL20001 and Sensortronics 60001.
BSS-5K
Qty:
Share on Facebook

Transcell BSS-5K is a non ntep Alloy Steel Easy to Install Stable & Reliable S-Type 5000 pound capacity Load Cell suitable for tension measurement, batching systems, blending & mixing, belt scales etc...

NTEP CoC: 97-028 (250 to 2.5k only)
MODEL
PART NUMBER
DESCRIPTION
BSS-250
52765-0014
250 lb Capacity-NTEP approved
BSS-500
52765-0022
500 lb Capacity-NTEP approved
BSS-1k
52765-0048
1000 lb Capacity-NTEP approved
BSS-2k
52765-0063
2000 lb Capacity-NTEP approved
BSS-2.5k
52765-0071
2500 lb Capacity-NTEP approved
BSS-3k
52765-0840
3000 lb Capacity
BSS-5k
52765-0089
5000 lb Capacity
BSS-10k
52765-0105
10,000 lb Capacity
Rated Output:
3.0mV/V±1%
Zero Balance:
±1% of rated output
Creep after 20 mintues:
0.03% of rated output
Non-linearity:
0.03% of rated output
Hysteresis:
0.02% of rated output
Repeatability:
0.02% of rated output
Temp. effect on output:
0.002% of applied output/°C
Temp. effect on zero:
0.002% of rated output/°C
Safe Temperature Range:
-10°C to +80°C
Temp Compensated:
-10°C to +50°C
Safe Overload:
1.5 x rated capacity
Input Impedance:
380ohm ±30ohm
Output Impedance:
350ohm ±3ohm
Insulation Resistance:
>5000 megohms
Rated Excitation:
10V DC/AC
Maximum Excitation:
20V DC/AC
Cable Length:
20 feet

Transcell BSS S-Beam 5000 lb. Load Cell

CAPACITY
T “Threads”
250 lb.
3/8-24 UNF-2B
500 - 1K lb.
1/2-20 UNF-2B
2K - 3K lb.
1/2-20 UNF-2B
5K - 10K lb.
3/4-16 UNF-2B
Similar to: Rice Lake RL20001, Vishay Sensortronics 60001 & Vishay Celtron STC
