VC-201 series Digital Weight Indicator

Standard Features

10,000 Display resolution ( NTEP )

10 Pre-defined Tare value

Selectable kg / lb / g / oz

Programmable as Main Indicator & Remote Display

Programmable custom print format

Configurable for Animal Weighing Application

Easy Panel Mount Design

Optional Re-chargeable battery

In order to cater for wider clienteles, we have developed a new cost competitive digital weight indicator – the VC-200 series that was launched recently on the market. This series comes in 3 models, the VC-201 (plastic casing), VC-202 (plastic casing) and VC-203 (stainless steel) affordably priced

Specifications Internal Resolution 1,000,000 counts at 3mV/V Display Resolution Selectable Input Sensitivity 1µV/graduation typical, 0.4µV/graduation minimum Display Increments Selectable x1, x2, x5, x10, x20, x50, x100 Decimal Point Location Selectable 0 ~ 4 Display 7 Digits 7-Segment LED display, 14.2mm (0.56”) high, with annunciators (7 LED lamps) for function select, Stable, Center Zero, Net, Print, kg, lb, and Low Battery display 135 Keyboard 6 button keypad with tactile keys (includes 1 button for Power On/Off) Audio Alarm Tone for key entry confirmation and low battery alarm A/D Conversion Rate 7.5 updates per second Load Cell Excitation Voltage 9.7VDC or 5VDC selectable. Drive up to six 350 ohm load cells Analog Input Range 0.2mV/V to 3.0 mV/V maximum Non-Linearity 0.01% of full scale or less Over Capacity Display “CAP OL” when exceeds the full scale capacity Tare Full capacity, push button tare Auto Zero Tracking Selectable to 3.0 d by 0.5 d step Motion Window Key-in data 0..255 (1 = 0.5 d) Calibration Method Software – Menu driven prompting Units of Measure Selectable kg/lb/g/oz, up to 2 units displayable RFI/EMI Protection All signal and excitation lines filtered to –65db min. @ 500MHz Filtering Selectable digital filter Serial RS232C Data Output COM Port 1. Full Duplex or Bi-directional COM Port 2. Simplex or Unidirectional (output only) Selectable baud rates (1200,2400,4800,9600,19200), manual or auto print, continuous data out or bi-directional communication Remote Display Programmable as Remote Display Print Format Gross Wt, Tare Wt, Net Wt Power 100/115VAC or 220/230VAC, 50-60Hz, 6VA with built-in Charger for 12 VDC 2-2.3AH Rechargeable Sealed Lead Acid Battery (Battery Dimension 67 (H) x 178 (W) x 34 (D) mm, is optional) Current Consumption 100mA + 30mA per 350 ? load cell Operating Temperature -10°C to + 40°C Relative Humidity Maximum 90% RH, Non-condensing Shipping Weight 1.2kg (2.3kg with optional battery Enclosure ABS Plastic Casing Warranty One Year Limited Warranty

Please email if you have any questions or would like to place an order today!
